The IMU F99 inclination sensor offers stable inclination values for mobile use on construction machinery or robots, with an integrated gyroscope compensating for accelerations, making it a superior choice over static sensors.
IMU F99—dynamic inclination sensor
Inclination sensors are capable of delivering extremely precise values in stationary conditions, but their measurements can be distorted by acceleration effects. However, in applications such as excavators, wheel loader buckets, and the booms of agricultural machines, inclination values are often required during movement. Conventional static inclination sensors are based on the measurement of gravitational force, but they also react to any other forces. As the acceleration changes, so does the inclination value.
Mobile machines require the position angle of booms while driving
In vehicles and mobile devices, this means that accelerating, braking, centrifugal forces in bends, and any vibrations while driving can distort the measured value. These influences must be compensated for to achieve dynamic inclination measurement. For this reason, Pepperl+Fuchs has developed the innovative IMU F99 device series for mobile inclination measurements. The addition of a rotation rate sensor (gyroscope) enables the sensor to perform dynamic inclination measurement. This allows precise inclination values to be recorded even during movement.
IMU F99—simple mounting with no need for mechanical customization of the machine
The IMU F99 sensor can therefore be used on all mobile machines for position detection, control and positioning of booms, anti-fall-over systems, steering angle restriction, and weighing systems.
www.pepperl-fuchs.com
